High Pressure Oxygen Booster Compressor
Structural Advantages
- The entire oxygen booster compressor operates without oil, eliminating the risk of oil contamination in high-pressure and high-purity oxygen, supporting safe operation.
- The absence of lubrication and oil distribution systems simplifies mechanical structure and ensures ease of operation.
- Oil-free compression ensures oxygen purity remains unchanged at both inlet and outlet of the booster.
- The cylinder filling oxygen booster is designed with an inlet pressure of 3-4 barg (40-60 psig) and a discharge pressure up to 150 bar (2150 psig).
Key Advantages
- 100% oil-free design eliminates the need for lubrication, while stainless steel cylinders ensure exceptional durability and long service life.
- Specifically engineered for PSA oxygen source boosting, ensuring maximum operational efficiency.
- Guaranteed zero-pollution operation to maintain consistent gas purity throughout the process.
- High-performance piston rings offer a service life of up to 4,000 hours under low-pressure conditions and 1,500-2,000 hours under high-pressure conditions.
- Flexible design supports single, two, three, or four-stage compression tailored to specific working conditions.
- Low-Speed Reliability: Operates at low speeds (260-400 rpm) to minimize wear and significantly enhance long-term reliability.
- Ultra-Quiet Operation: Average noise levels remain below 75 dB, making the unit ideal for medical and other noise-sensitive environments.
- Continuous Heavy-Duty Performance: Built for 24/7 uninterrupted service, ensuring stable performance even under the most demanding heavy-duty cycles.
